This is the factory drawing for the first type Foden Cab and Chassis used on the later 501/502/503/504/505, renumbered to 901 to 905 and the Tanker versions 941 and 942, produced from 1947 to 1952 (1st type) and from 1952 to 1964 (Various dates for the individual models).

These image have been donated to the DTCA by Mike Richardson.

This image is a photograph of a factory photostat of the Job 12163 for the type 1 Foden.

Type 1 Foden Chassis from 1947 to 1952.
